New – 2014
Cutting time: 780 Hours
SPECIFICATIONS:
Swing over front apron…………34.5″
Swing over cross slide…………25.5″
Swing over tailstock…………25.5″
Chuck size…………15″
Cutting length – maximum w/o workholding…………44″
Bar capacity…………4″
X-Axis travel…………17″
Z-Axis travel…………44″
X-Rapid feedrate…………710″/Min.
Z-Rapid feedrate…………710″/Min.
X-Thrust – maximum…………5,500 Lbs.
Z-Thrust – maximum…………9,000 Lbs.
Spindle power…………40 HP
Spindle speed – maximum…………2,400 RPM
Spindle torque – maximum…………1,400 ft-lb @ 150 RPM
Spindle nose…………A2-8
Spindle bore…………4.62″
Tool turret stations…………12
Floorspace required…………229″(L-R) x 139″(F-B)
Shipping dimensions…………205″ x 96″ x 95″(H)
Weight – approximate…………25,000 Lbs.
EQUIPPED WITH:
Haas CNC Control w/15″ color LCD monitor
Remote jog handle w/color LCD
High-torque live tooling w/C-axis
Hybrid BOT/VDI Turret
Programmable MT5 servo tailstock
Automatic tool presetter system
CNC control cabinet cooler
Belt type chip conveyor
High-intensity halogen lighting
Internal high-voltage isolated transformer
Rigid tapping
Extended tool pocket
*Catalog specifications subject to verification
