New – 2005
Serial No. 10-10357
SPECIFICATIONS:
Capacity:
– Swing Over Table…………17.7″
– Center Distance…………118.1″
– Grinding Diameter – Maximum…………16.9″
– Workpiece Weight – Maximum…………2,200 Lbs.
Grind Wheel:
– Wheel OD…………17.3″ – 24″
– Wheel ID…………10″
– Wheel Width…………3″
Wheelhead:
– Spindle Speed…………960 RPM
– Spindle Motor…………14.75 HP
– Manual Feed Stroke…………8.7″
– Rapid Feed Stroke…………2.4″
– Wheel Position Adjustment…………6.5″
– Handwheel Feed – One Revolution…………0.04″
– Handwheel Feed – One Division…………0.000098″
Automatic Infeed:
– Travel…………0.03″
– Plunge-Cut Speed…………0.0008 – 0.06 IPM
– Plunge-Cut Spark-Out Adjustment Range…………0 – 30 Sec.
– Automatic Traverse-Cut Rate…………0.00004 – 0.004
– Traverse-Cut Spark-Out Adjustment Range…………0 – 99 Sec.
Workhead Shigiya Cylindrical Grinder:
– Non-Swiveling Type – Dead Spindle
– Spindle Speeds (8)…………13 – 200 RPM
– Center Taper…………MT No. 5
– Center Height from Floor…………45.3″
Footstock:
– Spindle Stroke…………2″
– Center Taper…………MT No. 5
Table:
– CCW Swivel Angle…………5 Deg.
– CW Swivel Angle…………30 Deg.
– Handwheel Feed – One Revolution (Two Speeds)…………0.1″ – 0.6″
– Automatic Traverse Speed…………2 – 118 IPM
Machine Dimensions – Actual…………355″(L-R) x 84″(F-B)
Machine Weight – from Manual…………20,900 Lbs.
Shigiya Cylindrical Grinder GP-45B/300A EQUIPPED WITH:
Hydraulic Automatic Wheel Infeed
Hydraulic Rapid Wheel Infeed
Hydraulic Automatic Table Traverse
Infeed timer (workhead) In Traverse Cut Auto-Grinding
Infeed timer (footstock) In Traverse Cut Auto-Grinding
Spark-Out Timer, Spark-Out Counter
Table Dwell (Tarry)
SONY Model LH51 Digital Read-out (X-Axis In-Feed)
Angular Table Setting Vernier with Mitutoyo Gauge
Grinding Wheel Spindle Lubrication Unit
(6) Single Point Steady Rests
(1) Table Mount Wheel Dresser
Hydraulic Pump & Tank
Coolant System with Magnetic Separator and Oil Skimmer
Mist Collector with Hood
(20) OEM Mounting Pads
Books, Manuals, & Drawings
*Preliminary Specifications Subject to Verification
The Shigiya cylindrical grinder is a vital machine tool in the realm of precision machining. It efficiently grinds cylindrical and conical surfaces on workpieces with exceptional accuracy and smoothness. The grinder’s rotating abrasive wheel is adept at removing material, producing fine finishes, and achieving tight tolerances. Widely utilized across diverse industries, from aerospace to automotive, the Shigiya cylindrical grinder enhances productivity and ensures the high-quality production of shafts, rods, and other cylindrical components.
